Drive Configuration
Interface: ATA-7
Bytes per Sector: 512
Buffer Size: 2 Mbytes
Performance Specification
Read Seek Time (Typical)
Track to Track: 0.8 ms
Average: 8.9 ms
Full Stroke: 18.0 ms
Average Latency: 4.17 ms
Rotational Speed: 7,200 rpm
Data Transfer Rate
Media to/from Buffer (max.): 741 Mbits/sec
Buffer to/from Host (max.): 133 Mbytes/sec
Drive Ready Time (typical): 7 sec
Reliability Specification
Non-recoverable Read Error: 1 sector in 1014bits
MTBF: 500,000 POH
Start/Stop Cycles (Ambient): 50,000
Component Design Life: 5 years
Acoustic (Average Sound Power)
Idle: 2.7 Bel
Random Read/Write: 2.8 Bel
Environmental Specification
Temperature
Operating: 5 ~ 55oC
Non-operating: -40 ~ 70oC
Thermal Gradient (max.): 20oC/hr
Humidity (non-condensing)
Operating: 5 ~ 90 %
Non-operating: 5 ~ 95 %
Linear Shock
Operating, 2ms: 63 G
Non-operating, 2ms: 350 G
Vibration (swept sine, 1 octave per minute)20
Linear Shock (1/2 sine pulse)
Operating
|
